Redefining Compact Intelligence
Compact Size. Powerful Awareness
A 48MP wide-angle camera and telephoto zoom camera work together to capture both broad scenes and distant details with exceptional clarity.
With AI recognition and tracking technology, the system can automatically identify and reliably track moving targets such as people and vehicles.
Capture distant targets with exceptional clarity, revealing critical details such as vehicle license plates from up to 200 meters away.
License Plate Recognition at 200m
Supporting up to 160× hybrid zoom and 11× optical zoom, the system delivers both long-range observation and detailed target inspection.
AI Tracking. Lock On Target
Powered by a 6 TOPS AI processor, the system automatically detects, identifies, and tracks people, vehicles, and other targets. Even in high-speed scenarios, it maintains stable tracking and clear imagery.
Dual Camera System
Combining wide-area situational awareness with long-range target observation, it provides a more complete operational view.
Specifications
| Weight | 162g ±5g |
| Operating Voltage | 12V-18V |
| Axis Type | 3-Axis Mechanical Stabilization |
| Software Angle Limits |
Pitch: -90° to +30° Yaw: -120° to +120° |
| Mechanical Range |
Pitch: -135° to +45° Roll: -45° to +45° Yaw: -135° to +135° |
| Max Control Speed | 180°/s |
| Angular Vibration Range | ±0.005° |
| Interfaces | Ethernet / Serial Port / SBUS |
| Gimbal Mode | Target Recognition, Auto Tracking |
| Operating Temperature | -40℃ ~ +65℃ |
| Communication Protocol | HEQ Proprietary Protocol |
| IP Rating | IP44 |
| Power Consumption | 8W |
| Hybrid Zoom | 40× |
| Visible Light Resolution | 4K (Wide-Angle) |
| TF Card Photo Format | JPG |
| TF Card Video Format | MP4 |
| Video Resolution | 4K @30fps |
| Encoding Format | H.264, H.265 |
| AI Recognition & Tracking | Supported |
| Wide-Angle Camera | |
| Sensor Size | 1/2.8" |
| Focal Length | 8mm |
| Effective Pixels | 8MP |
| Aperture | F1.6 |
| FOV | H:42.2° V:23.4° D:48.8° |
| Thermal Camera | |
| Detector Type | VOx Uncooled Infrared Focal Plane Detector |
| Thermal Resolution | 640 × 512 / 1280 × 1024 (Thermal Super-Resolution) |
| Pixel Pitch | 12μm |
| Frame Rate | 25Hz / 30Hz |
| Spectral Band | 8~14μm |
| Focal Length | 13.5mm |
| FOV | 31.9° × 25.7° |
| Aperture | F1.0 |
Softwares
Documents
I'd like to buy one, but I'm worried it might be difficult to use.
You can visit the HEQ YouTube channel to watch our tutorial series before making a purchase decision.
We also publish firmware updates, setup guides, and feature demonstrations on the channel to help users get the most out of their gimbals.
